دیتاشیت LTC4310IDD-2#TRPBF
مشخصات دیتاشیت
| نام دیتاشیت | LTC4310-1/-2 |
|---|---|
| حجم فایل | 241.12 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 20 |
دانلود دیتاشیت LTC4310-1/-2 |
LTC4310-1/-2 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Communication Interface Chip/UART/485/232/Digital Isolators
- Datasheet: Analog Devices LTC4310IDD-2#TRPBF
- Applications: I2C
- Supply Voltage: 3V~5.5V
- Forward Channel: 1
- Reverse channel: 1
- Number of Channels: 2
- Isolation Technology: Magnetic isolation
- Operating Temperature: -40°C~+85°C
- Voltage Isolation or Not: Without voltage isolation
- Package: DFN-10(3x3)
- Manufacturer: Analog Devices
- Series: -
- Packaging: Tape & Reel (TR)
- Part Status: Active
- Technology: Magnetic Coupling
- Type: I²C
- Isolated Power: No
- Inputs - Side 1/Side 2: 1/1
- Channel Type: Unidirectional
- Voltage - Isolation: -
- Common Mode Transient Immunity (Min): 20kV/µs
- Data Rate: 400kHz
- Propagation Delay tpLH / tpHL (Max): -
- Pulse Width Distortion (Max): -
- Rise / Fall Time (Typ): 1ns, 1ns
- Voltage - Supply: 3V ~ 5.5V
- Mounting Type: Surface Mount
- Package / Case: 10-WFDFN Exposed Pad
- Supplier Device Package: 10-DFN (3x3)
- Base Part Number: LTC4310
- detail: I²C Digital Isolator 2 Channel 400kHz 20kV/µs CMTI 10-WFDFN Exposed Pad
