دیتاشیت LT3048IDC-12#TRMPBF
مشخصات دیتاشیت
| نام دیتاشیت | LT3048 Series |
|---|---|
| حجم فایل | 1617.249 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 16 |
دانلود دیتاشیت LT3048 Series |
LT3048 Series Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/DC-DC Converters
- Datasheet: Analog Devices LT3048IDC-12#TRMPBF
- Input Voltage: 2.7V~4.8V
- Number of Outputs: 2
- Switching Frequency: 2.2MHz
- Operating Temperature: -40°C~+125°C
- Package: DFN-8(2x2)
- Manufacturer: Analog Devices
- Series: -
- Packaging: Tape & Reel (TR)
- Part Status: Active
- Topology: Step-Up (Boost) (1), Linear (LDO) (1)
- Frequency - Switching: 2.2MHz
- Voltage/Current - Output 1: 13.1V, 300mA
- Voltage/Current - Output 2: 12V, 45mA
- Voltage/Current - Output 3: -
- w/LED Driver: No
- w/Supervisor: No
- w/Sequencer: No
- Voltage - Supply: 2.7V ~ 4.8V
- Mounting Type: Surface Mount
- Package / Case: 8-WFDFN Exposed Pad
- Supplier Device Package: 8-DFN (2x2)
- Base Part Number: LT3048
- detail: PMIC - Voltage Regulators - Linear + Switching 2 Output Step-Up (Boost) (1), Linear (LDO) (1) 2.2MHz 8-DFN (2x2)
