دیتاشیت LT1244CN8#PBF

LT1241-45 Datasheet

مشخصات دیتاشیت

نام دیتاشیت LT1241-45 Datasheet
حجم فایل 1211.668 کیلوبایت
نوع فایل pdf
تعداد صفحات 20

دانلود دیتاشیت LT1241-45 Datasheet

LT1241-45 Datasheet Datasheet

مشخصات

  • RoHS: true
  • Category: Power Supply Chip/AC-DC Controllers & Regulators
  • Datasheet: Analog Devices LT1244CN8#PBF
  • Package: PDIP-8
  • Manufacturer: Analog Devices
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • Output Isolation: Isolated
  • Internal Switch(s): No
  • Voltage - Breakdown: -
  • Topology: Buck
  • Voltage - Start Up: 16V
  • Voltage - Supply (Vcc/Vdd): 10V ~ 25V
  • Duty Cycle: 48%
  • Frequency - Switching: Up to 500kHz
  • Fault Protection: -
  • Control Features: Frequency Control
  • Operating Temperature: 0°C ~ 100°C (TJ)
  • Package / Case: 8-DIP (0.300", 7.62mm)
  • Supplier Device Package: 8-PDIP
  • Mounting Type: Through Hole
  • Base Part Number: LT1244
  • detail: Converter Offline Buck Topology Up to 500kHz 8-PDIP
