MIC5209-3.0BS Datasheet

MIC5209

Datasheet specifications

Datasheet's name MIC5209
File size 1534.848 KB
File type pdf
Number of pages 30

Download Datasheet MIC5209

Download Datasheet

Other documentations

No other documentation was found!

Technical specifications

  • Manufacturer: Microchip Technology
  • Series: -
  • Packaging: Tube
  • Part Status: Obsolete
  • Output Configuration: Positive
  • Output Type: Fixed
  • Number of Regulators: 1
  • Voltage - Input (Max): 16V
  • Voltage - Output (Min/Fixed): 3V
  • Voltage - Output (Max): -
  • Voltage Dropout (Max): 0.6V @ 500mA
  • Current - Output: 500mA
  • Current - Quiescent (Iq): 170µA
  • Current - Supply (Max): 25mA
  • PSRR: 75dB (120Hz)
  • Control Features: -
  • Protection Features: Over Current, Over Temperature, Reverse Polarity
  • Operating Temperature: -40°C ~ 125°C
  • Mounting Type: Surface Mount
  • Package / Case: TO-261-4, TO-261AA
  • Supplier Device Package: SOT-223-3
  • Base Part Number: MIC5209
  • detail: Linear Voltage Regulator IC 1 Output 500mA SOT-223-3
