دیتاشیت LTC3672BEDC-2#TRMPBF
مشخصات دیتاشیت
| نام دیتاشیت | LTC3672B-2 |
|---|---|
| حجم فایل | 161.212 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 12 |
دانلود دیتاشیت LTC3672B-2 |
LTC3672B-2 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/DC-DC Converters
- Datasheet: Analog Devices LTC3672BEDC-2#TRMPBF
- Input Voltage: 2.9V~5.5V
- Number of Outputs: 3
- Switching Frequency: 2.25MHz
- Operating Temperature: -40°C~+85°C
- Package: DFN-8(2x2)
- Manufacturer: Analog Devices
- Series: -
- Packaging: Tape & Reel (TR)
- Part Status: Active
- Topology: Step-Down (Buck) Synchronous (1), Linear (LDO) (2)
- Frequency - Switching: 2.25MHz
- Voltage/Current - Output 1: 1.2V, 400mA
- Voltage/Current - Output 2: 2.8V, 150mA
- Voltage/Current - Output 3: 1.8V, 150mA
- w/LED Driver: No
- w/Supervisor: No
- w/Sequencer: No
- Voltage - Supply: 2.9V ~ 5.5V
- Mounting Type: Surface Mount
- Package / Case: 8-WFDFN Exposed Pad
- Supplier Device Package: 8-DFN (2x2)
- Base Part Number: LTC3672
- detail: PMIC - Voltage Regulators - Linear + Switching 3 Output Step-Down (Buck) Synchronous (1), Linear (LDO) (2) 2.25MHz 8-DFN (2x2)
