دیتاشیت LTC1551CS8-4.1#TRPBF
مشخصات دیتاشیت
| نام دیتاشیت | LTC1550/51 |
|---|---|
| حجم فایل | 299.85 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 12 |
دانلود دیتاشیت LTC1550/51 |
LTC1550/51 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/DC-DC Converters
- Function: Buck-boost type
- Topology: -
- Datasheet: Analog Devices LTC1551CS8-4.1#TRPBF
- Output Type: Fixed
- Input Voltage: 4.5V~6.5V
- Output Voltage: -4.1V
- Number of Outputs: 1
- Switching Frequency: 900kHz
- Output Current (Max): 10mA
- Operating Temperature: 0°C~+70°C@(TA)
- Synchronous Rectification: NO
- Package: SOP-8
- Manufacturer: Analog Devices
- Series: -
- Packaging: Tape & Reel (TR)
- Part Status: Active
- Output Configuration: Negative
- Voltage - Input (Min): 4.5V
- Voltage - Input (Max): 6.5V
- Voltage - Output (Min/Fixed): -4.1V
- Voltage - Output (Max): -
- Current - Output: 10mA
- Frequency - Switching: 900kHz
- Synchronous Rectifier: No
- Mounting Type: Surface Mount
- Package / Case: 8-SOIC (0.154", 3.90mm Width)
- Supplier Device Package: 8-SOIC
- Base Part Number: LTC1551
- detail: Charge Pump Switching Regulator IC Negative Fixed -4.1V 1 Output 10mA 8-SOIC (0.154", 3.90mm Width)
