دیتاشیت LTC1504ACS8#TRPBF
مشخصات دیتاشیت
| نام دیتاشیت | LTC1504A |
|---|---|
| حجم فایل | 110.919 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 12 |
دانلود دیتاشیت LTC1504A |
LTC1504A Datasheet |
|---|
مشخصات
- Manufacturer: Linear Technology/Analog Devices
- Series: -
- Packaging: Tape & Reel (TR)
- Part Status: Active
- Function: Step-Down
- Output Configuration: Positive
- Topology: Buck
- Output Type: Adjustable
- Number of Outputs: 1
- Voltage - Input (Min): 4V
- Voltage - Input (Max): 10V
- Voltage - Output (Min/Fixed): 1.265V
- Voltage - Output (Max): 10V
- Current - Output: 500mA
- Frequency - Switching: 200kHz
- Synchronous Rectifier: Yes
- Operating Temperature: 0°C ~ 70°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 8-SOIC (0.154", 3.90mm Width)
- Supplier Device Package: 8-SOIC
- Base Part Number: LTC1504
- detail: Buck Switching Regulator IC Positive Adjustable 1.265V 1 Output 500mA 8-SOIC (0.154", 3.90mm Width)
