دیتاشیت SI1081-A-GM
مشخصات دیتاشیت
| نام دیتاشیت | Si106x/108x Datasheet |
|---|---|
| حجم فایل | 10560.212 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 358 |
دانلود دیتاشیت Si106x/108x Datasheet |
Si106x/108x Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Radio Frequency Chip/Antenna/RF Transceiver ICs
- Data Rate: 1Mbps
- Datasheet: SILICON LABS SI1081-A-GM
- Interface: I2C,SPI,UART
- Applications: General-purpose ISM<1GHz
- Frequency Range: 142MHz~1.05GHz
- Receive Current: 10.7mA
- Operating Voltage: 1.8V~3.6V
- Operating Temperature: -40°C~+85°C
- Current Of Transmitting: 70mA
- Package: QFN-36-EP(5x6)
- Manufacturer: SILICON LABS
- Sensitivity: -126dBm
- Series: -
- Voltage - Supply: 1.8V ~ 3.6V
- Type: TxRx + MCU
- Frequency: 142MHz ~ 1.05GHz
- Mounting Type: Surface Mount
- Package / Case: 36-WFQFN Exposed Pad
- Modulation: 4FSK, 4GFSK, FSK, GFSK, OOK
- Supplier Device Package: 36-QFN (5x6)
- Packaging: Tray
- Data Rate (Max): 1Mbps
- GPIO: 15
- Power - Output: 20dBm
- Current - Receiving: 10.7mA ~ 13.7mA
- RF Family/Standard: General ISM < 1GHz
- Protocol: -
- Part Status: Active
- Serial Interfaces: I²C, SPI, UART
- Memory Size: 8kB Flash, 768B RAM
- Current - Transmitting: 70mA ~ 85mA
- detail: IC RF TxRx + MCU General ISM < 1GHz 142MHz ~ 1.05GHz 36-WFQFN Exposed Pad
