دیتاشیت LTC3423EMS#PBF
مشخصات دیتاشیت
| نام دیتاشیت |
LTC3423-24
|
| حجم فایل |
211.382
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
12
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/DC-DC Converters
-
Function:
boost converterType
-
Topology:
Boost
-
Datasheet:
Analog Devices LTC3423EMS#PBF
-
Output Type:
Adjustable
-
Input Voltage:
0.5V~5.5V
-
Output Voltage:
1.5V~5.5V
-
Number of Outputs:
1
-
Switching Frequency:
3MHz
-
Output Current (Max):
1A
-
Operating Temperature:
-40°C~+85°C@(TA)
-
Synchronous Rectification:
NO
-
Package:
MSOP-10
-
Manufacturer:
Analog Devices
-
Series:
-
-
Packaging:
Tube
-
Part Status:
Active
-
Output Configuration:
Positive
-
Voltage - Input (Min):
0.5V
-
Voltage - Input (Max):
5.5V
-
Voltage - Output (Min/Fixed):
1.5V
-
Voltage - Output (Max):
5.5V
-
Current - Output:
1A (Switch)
-
Frequency - Switching:
Up to 3MHz
-
Synchronous Rectifier:
No
-
Mounting Type:
Surface Mount
-
Package / Case:
10-TFSOP, 10-MSOP (0.118", 3.00mm Width)
-
Supplier Device Package:
10-MSOP
-
Base Part Number:
LTC3423
-
detail:
Boost Switching Regulator IC Positive Adjustable 1.5V 1 Output 1A (Switch) 10-TFSOP, 10-MSOP (0.118", 3.00mm Width)
