دیتاشیت ATA6838-PXQW

ATA6838

مشخصات دیتاشیت

نام دیتاشیت ATA6838
حجم فایل 380.728 کیلوبایت
نوع فایل pdf
تعداد صفحات 18

دانلود دیتاشیت ATA6838

ATA6838 Datasheet

مشخصات

  • Manufacturer: Microchip Technology
  • Series: -
  • Packaging: Tape & Reel (TR)
  • Part Status: Obsolete
  • Motor Type - Stepper: -
  • Motor Type - AC, DC: Brushed DC
  • Function: Driver - Fully Integrated, Control and Power Stage
  • Output Configuration: Half Bridge (6)
  • Interface: SPI
  • Technology: Power MOSFET
  • Step Resolution: -
  • Applications: General Purpose
  • Current - Output: 1A
  • Voltage - Supply: 4.75V ~ 5.25V
  • Voltage - Load: 5.5V ~ 40V
  • Operating Temperature: -40°C ~ 150°C (TJ)
  • Mounting Type: Surface Mount
  • Package / Case: 24-VQFN Exposed Pad
  • Supplier Device Package: 24-VQFN (5x5)
  • Base Part Number: ATA6838
  • detail: Motor Driver Power MOSFET SPI 24-VQFN (5x5)
