- دیتاشیت LTC3548EDD-2#TRPBF
دیتاشیت LTC3548EDD-2#TRPBF
مشخصات دیتاشیت
| نام دیتاشیت | LTC3548-2 |
|---|---|
| حجم فایل | 418.284 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 16 |
دانلود دیتاشیت LTC3548-2 |
LTC3548-2 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/DC-DC Converters
- Function: Step-down type;Buck-boost type
- Topology: Step-down;Step-down-Boost
- Datasheet: Analog Devices LTC3548EDD-2#TRPBF
- Output Type: 可调和固定
- Input Voltage: 2.5V~5.5V
- Output Voltage: 0.6V~5.5V
- Number of Outputs: 2
- Switching Frequency: 2.25MHz
- Output Current (Max): 700mA;1.2A
- Operating Temperature: -40°C~+85°C@(TA)
- Synchronous Rectification: Yes
- Package: DFN-10(3x3)
- Manufacturer: Analog Devices
- Series: -
- Packaging: Tape & Reel (TR)
- Part Status: Active
- Output Configuration: Positive
- Voltage - Input (Min): 2.5V
- Voltage - Input (Max): 5.5V
- Voltage - Output (Min/Fixed): 0.6V (1.8V)
- Voltage - Output (Max): 5.5V
- Current - Output: 700mA, 1.2A
- Frequency - Switching: 2.25MHz
- Synchronous Rectifier: Yes
- Mounting Type: Surface Mount
- Package / Case: 10-WFDFN Exposed Pad
- Supplier Device Package: 10-DFN (3x3)
- Base Part Number: LTC3548
- detail: Buck, Buck-Boost Switching Regulator IC Positive Adjustable (Fixed) 0.6V (1.8V) 2 Output 700mA, 1.2A 10-WFDFN Exposed Pad
