دیتاشیت LTC3642EDD-5#TRPBF

مشخصات دیتاشیت

دانلود دیتاشیت LTC3642 Datasheet	LTC3642 Datasheet Datasheet

RoHS: true
Category: Power Supply Chip/DC-DC Converters
Function: Step-down type
Topology: Step-down
Datasheet: Analog Devices LTC3642EDD-5#TRPBF
Output Type: Fixed
Input Voltage: 4.5V~45V
Output Voltage: 5V
Number of Outputs: 1
Switching Frequency: -
Output Current (Max): 50mA
Operating Temperature: -40°C~+125°C@(TJ)
Synchronous Rectification: Yes
Package: DFN-8(3x3)
Manufacturer: Analog Devices
Series: -
Packaging: Tape & Reel (TR)
Part Status: Active
Output Configuration: Positive
Voltage - Input (Min): 4.5V
Voltage - Input (Max): 45V
Voltage - Output (Min/Fixed): 5V
Voltage - Output (Max): -
Current - Output: 50mA
Frequency - Switching: -
Synchronous Rectifier: Yes
Mounting Type: Surface Mount
Package / Case: 8-WFDFN Exposed Pad
Supplier Device Package: 8-DFN (3x3)
Base Part Number: LTC3642
detail: Buck Switching Regulator IC Positive Fixed 5V 1 Output 50mA 8-WFDFN Exposed Pad
