LT308x Selector Card Datasheet
Datasheet specifications
| Datasheet's name | LT308x Selector Card |
|---|---|
| File size | 834.46 KB |
| File type | |
| Number of pages | 2 |
Download Datasheet LT308x Selector Card |
Download Datasheet |
|---|
Other documentations
LT3081 Datasheet 32 pages
LT3081ET7#PBF 32 pages
Technical specifications
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Analog Devices LT3081ET7#06PBF
- Output Type: Adjustable
- Output Current: 1.5A
- Output Voltage: 0V~34.5V
- Dropout Voltage: 1.5V@(1.5A)
- Output Polarity: positive
- Number of Outputs: 1
- Maximum Input Voltage: 36V
- Operating Temperature: -40°C~+125°C
- Quiescent Current (Ground Current): 50uA
- Package: TO-220-7
- Manufacturer: Analog Devices
- Series: -
- Packaging: Tube
- Part Status: Active
- Output Configuration: Positive
- Number of Regulators: 1
- Voltage - Input (Max): 36V
- Voltage - Output (Min/Fixed): 0V
- Voltage - Output (Max): 34.5V
- Voltage Dropout (Max): 1.5V @ 1.5A
- Current - Output: 1.5A
- Current - Quiescent (Iq): 50µA
- Current - Supply (Max): 5mA
- PSRR: 90dB ~ 20dB (120Hz ~ 1MHz)
- Control Features: Current Limit
- Protection Features: Over Current, Over Temperature, Reverse Polarity, Short Circuit
- Mounting Type: Through Hole
- Package / Case: TO-220-7
- Supplier Device Package: TO-220-7 Flow 6
- Base Part Number: LT3081
- detail: Linear Voltage Regulator IC 1 Output 1.5A TO-220-7 Flow 6
