دیتاشیت LTC3407EDD-4#TRPBF
مشخصات دیتاشیت
| نام دیتاشیت | LTC3407-4 |
|---|---|
| حجم فایل | 274.611 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 16 |
دانلود دیتاشیت LTC3407-4 |
LTC3407-4 Datasheet |
|---|
مشخصات
- Manufacturer: Linear Technology/Analog Devices
- Series: -
- Packaging: Tape & Reel (TR)
- Part Status: Active
- Function: Step-Down
- Output Configuration: Positive
- Topology: Buck
- Output Type: Adjustable
- Number of Outputs: 2
- Voltage - Input (Min): 2.5V
- Voltage - Input (Max): 5.5V
- Voltage - Output (Min/Fixed): 0.6V
- Voltage - Output (Max): 5V
- Current - Output: 800mA
- Frequency - Switching: 2.25MHz
- Synchronous Rectifier: Yes
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 10-WFDFN Exposed Pad
- Supplier Device Package: 10-DFN (3x3)
- Base Part Number: LTC3407
- detail: Buck Switching Regulator IC Positive Adjustable 0.6V 2 Output 800mA 10-WFDFN Exposed Pad
