دیتاشیت LT1424CS8-9#TRPBF

مشخصات دیتاشیت

دانلود دیتاشیت LT1424-9	LT1424-9 Datasheet

RoHS: true
Category: Power Supply Chip/DC-DC Converters
Function: Buck-boost type
Topology: Flyback
Datasheet: Analog Devices LT1424CS8-9#TRPBF
Output Type: Fixed
Input Voltage: 2.8V~20V
Output Voltage: 9V
Number of Outputs: 1
Switching Frequency: 285kHz
Output Current (Max): 200mA
Operating Temperature: 0°C~+125°C@(TJ)
Synchronous Rectification: NO
Package: SOP-8
Manufacturer: Analog Devices
Series: -
Packaging: Tape & Reel (TR)
Part Status: Active
Output Configuration: Positive or Negative, Isolation Capable
Voltage - Input (Min): 2.8V
Voltage - Input (Max): 20V
Voltage - Output (Min/Fixed): 9V
Voltage - Output (Max): -
Current - Output: 200mA
Frequency - Switching: 285kHz
Synchronous Rectifier: No
Mounting Type: Surface Mount
Package / Case: 8-SOIC (0.154", 3.90mm Width)
Supplier Device Package: 8-SOIC
Base Part Number: LT1424
detail: Flyback Switching Regulator IC Positive or Negative, Isolation Capable Fixed 9V 1 Output 200mA 8-SOIC (0.154", 3.90mm Width)
