LTpowerCAD II User Guide 数据手册
数据手册规格
| 数据手册名称 | LTpowerCAD II User Guide |
|---|---|
| 文件大小 | 5376.71 千字节 |
| 文件类型 | |
| 页数 | 60 |
下载数据手册 LTpowerCAD II User Guide |
下载数据手册 |
|---|
其他文档
LTC3624(-2) Datasheet 20 pages
LTC3624EDD-2#TRPBF 20 pages
技术规格
- RoHS: true
- Category: Power Supply Chip/DC-DC Converters
- Function: Step-down type
- Topology: Step-down
- Datasheet: Analog Devices LTC3624IMSE#TRPBF
- Output Type: Adjustable
- Input Voltage: 2.7V~17V
- Output Voltage: 0.6V~17V
- Number of Outputs: 1
- Switching Frequency: 1MHz
- Output Current (Max): 2A
- Operating Temperature: -40°C~+125°C@(TJ)
- Synchronous Rectification: Yes
- Package: MSOP-12-EP
- Manufacturer: Analog Devices
- Series: -
- Packaging: Tape & Reel (TR)
- Part Status: Active
- Output Configuration: Positive
- Voltage - Input (Min): 2.7V
- Voltage - Input (Max): 17V
- Voltage - Output (Min/Fixed): 0.6V
- Voltage - Output (Max): 17V
- Current - Output: 2A
- Frequency - Switching: 1MHz
- Synchronous Rectifier: Yes
- Mounting Type: Surface Mount
- Package / Case: 12-TSSOP (0.118", 3.00mm Width) Exposed Pad
- Supplier Device Package: 12-MSOP-EP
- Base Part Number: LTC3624
- detail: Buck Switching Regulator IC Positive Adjustable 0.6V 1 Output 2A 12-TSSOP (0.118", 3.00mm Width) Exposed Pad
