دیتاشیت LT1303IS8-5#TRPBF
مشخصات دیتاشیت
| نام دیتاشیت | LT1303/-5 |
|---|---|
| حجم فایل | 259.827 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 12 |
دانلود دیتاشیت LT1303/-5 |
LT1303/-5 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/DC-DC Converters
- Function: boost converterType
- Topology: Boost
- Datasheet: Analog Devices LT1303IS8-5#TRPBF
- Output Type: Fixed
- Input Voltage: 1.8V~10V
- Output Voltage: 5V
- Number of Outputs: 1
- Switching Frequency: 155kHz
- Output Current (Max): 750mA
- Operating Temperature: 0°C~+70°C@(TA)
- Synchronous Rectification: NO
- Package: SO-8
- Manufacturer: Analog Devices
- Series: -
- Packaging: Tape & Reel (TR)
- Part Status: Active
- Output Configuration: Positive
- Voltage - Input (Min): 1.8V
- Voltage - Input (Max): 10V
- Voltage - Output (Min/Fixed): 5V
- Voltage - Output (Max): -
- Current - Output: 750mA (Switch)
- Frequency - Switching: 155kHz
- Synchronous Rectifier: No
- Mounting Type: Surface Mount
- Package / Case: 8-SOIC (0.154", 3.90mm Width)
- Supplier Device Package: 8-SOIC
- Base Part Number: LT1303
- detail: Boost Switching Regulator IC Positive Fixed 5V 1 Output 750mA (Switch) 8-SOIC (0.154", 3.90mm Width)
