دیتاشیت LT1529CT-5#30PBF

LT1529(-3.3,-5)

مشخصات دیتاشیت

نام دیتاشیت LT1529(-3.3,-5)
حجم فایل 153.843 کیلوبایت
نوع فایل pdf
تعداد صفحات 12

دانلود دیتاشیت LT1529(-3.3,-5)

LT1529(-3.3,-5) Datasheet

مشخصات

  • Manufacturer: Linear Technology/Analog Devices
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • Output Configuration: Positive
  • Output Type: Fixed
  • Number of Regulators: 1
  • Voltage - Input (Max): 15V
  • Voltage - Output (Min/Fixed): 5V
  • Voltage - Output (Max): -
  • Voltage Dropout (Max): 0.95V @ 3A
  • Current - Output: 3A
  • Current - Quiescent (Iq): 100µA
  • Current - Supply (Max): 160mA
  • PSRR: 62dB (120Hz)
  • Control Features: Enable
  • Protection Features: Over Current, Over Temperature, Reverse Polarity
  • Operating Temperature: 0°C ~ 125°C
  • Mounting Type: Through Hole
  • Package / Case: TO-220-5 Formed Leads
  • Supplier Device Package: TO-220-5 Flow 30
  • Base Part Number: LT1529
  • detail: Linear Voltage Regulator IC 1 Output 3A TO-220-5 Flow 30
