دیتاشیت LT3756JMSE-2#TRPBF

مشخصات دیتاشیت

دانلود دیتاشیت LT3756(-1,-2)	LT3756(-1,-2) Datasheet

RoHS: true
Type: DC-DCController
Dimming: Analog;PWM
Category: Nixie Tube Driver/LED Driver/LED Drivers
Channels: 1
Topology: Flyback,SEPIC,Step-down,boost converter
Datasheet: Analog Devices LT3756JMSE-2#TRPBF
Input Voltage: 6V~100V
Output Voltage: 100V
Switch Frequency: 100kHz~1MHz
Operating temperature: -40°C~+150°C
Package: MSOP-16-EP
Manufacturer: Analog Devices
Series: True Color PWM™
Packaging: Tape & Reel (TR)
Part Status: Active
Internal Switch(s): No
Number of Outputs: 1
Voltage - Supply (Min): 6V
Voltage - Supply (Max): 100V
Voltage - Output: 100V
Current - Output / Channel: -
Frequency: 100kHz ~ 1MHz
Applications: LED Lighting
Mounting Type: Surface Mount
Package / Case: 16-TFSOP (0.118", 3.00mm Width) Exposed Pad
Supplier Device Package: 16-MSOP-EP
detail: LED Driver IC 1 Output DC DC Controller Flyback, SEPIC, Step-Down (Buck), Step-Up (Boost) Analog, PWM Dimming 16-MSOP-EP
