دیتاشیت LTC1514CS8-3.3#PBF
مشخصات دیتاشیت
| نام دیتاشیت | LTC1514-3.3/-5 |
|---|---|
| حجم فایل | 220.849 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 8 |
دانلود دیتاشیت LTC1514-3.3/-5 |
LTC1514-3.3/-5 Datasheet |
|---|
مشخصات
- Manufacturer: Linear Technology/Analog Devices
- Series: -
- Packaging: Tube
- Part Status: Active
- Function: Step-Up/Step-Down
- Output Configuration: Positive
- Topology: Charge Pump
- Output Type: Fixed
- Number of Outputs: 1
- Voltage - Input (Min): 2V
- Voltage - Input (Max): 8V
- Voltage - Output (Min/Fixed): 3.3V
- Voltage - Output (Max): -
- Current - Output: 50mA
- Frequency - Switching: 650kHz
- Synchronous Rectifier: No
- Operating Temperature: 0°C ~ 70°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 8-SOIC (0.154", 3.90mm Width)
- Supplier Device Package: 8-SOIC
- Base Part Number: LTC1514
- detail: Charge Pump Switching Regulator IC Positive Fixed 3.3V 1 Output 50mA 8-SOIC (0.154", 3.90mm Width)
