دیتاشیت LT3973HMSE-5#TRPBF

مشخصات دیتاشیت

دانلود دیتاشیت LT3973(-3.3,-5) Datasheet	LT3973(-3.3,-5) Datasheet Datasheet

RoHS: true
Category: Power Supply Chip/DC-DC Converters
Function: Step-down type
Topology: Step-down
Datasheet: Analog Devices LT3973HMSE-5#TRPBF
Output Type: Fixed
Input Voltage: 4.2V~42V
Output Voltage: 5V
Number of Outputs: 1
Switching Frequency: 2.15MHz
Output Current (Max): 750mA
Operating Temperature: -40°C~+150°C@(TJ)
Synchronous Rectification: NO
Package: MSOP-10-EP
Manufacturer: Analog Devices
Series: -
Packaging: Tape & Reel (TR)
Part Status: Active
Output Configuration: Positive
Voltage - Input (Min): 4.2V
Voltage - Input (Max): 42V
Voltage - Output (Min/Fixed): 5V
Voltage - Output (Max): -
Current - Output: 750mA
Frequency - Switching: 195kHz ~ 2.15MHz
Synchronous Rectifier: No
Mounting Type: Surface Mount
Package / Case: 10-TFSOP, 10-MSOP (0.118", 3.00mm Width) Exposed Pad
Supplier Device Package: 10-MSOP-EP
Base Part Number: LT3973
detail: Buck Switching Regulator IC Positive Fixed 5V 1 Output 750mA 10-TFSOP, 10-MSOP (0.118", 3.00mm Width) Exposed Pad
