دیتاشیت LT8331IMSE#WPBF
مشخصات دیتاشیت
| نام دیتاشیت |
LT8331
|
| حجم فایل |
1461.494
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
30
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/DC-DC Converters
-
Function:
boost converterType;Buck-boost type
-
Topology:
Boost;Flyback;SEPIC
-
Datasheet:
Analog Devices LT8331IMSE#WPBF
-
Output Type:
Adjustable
-
Input Voltage:
4.5V~100V
-
Output Voltage:
1.6V;-0.8V~140V
-
Number of Outputs:
1
-
Switching Frequency:
500kHz
-
Output Current (Max):
500mA
-
Operating Temperature:
-40°C~+125°C@(TJ)
-
Synchronous Rectification:
NO
-
Package:
MSOP-12
-
Manufacturer:
Analog Devices
-
Series:
Automotive, AEC-Q100
-
Packaging:
Tube
-
Part Status:
Active
-
Output Configuration:
Positive or Negative, Isolation Capable
-
Voltage - Input (Min):
4.5V
-
Voltage - Input (Max):
100V
-
Voltage - Output (Min/Fixed):
1.6V, -0.8V
-
Voltage - Output (Max):
140V (Switch)
-
Current - Output:
500mA (Switch)
-
Frequency - Switching:
100kHz ~ 500kHz
-
Synchronous Rectifier:
No
-
Mounting Type:
Surface Mount
-
Package / Case:
16-TFSOP (0.118", 3.00mm Width), 12 Leads, Exposed Pad
-
Supplier Device Package:
16-MSOP-EP
-
detail:
Boost, Flyback, SEPIC Switching Regulator IC Positive or Negative, Isolation Capable Adjustable 1.6V, -0.8V 1 Output 500mA (Switch) 16-TFSOP (0.118", 3.00mm Width), 12 Leads, Exposed Pad
