دیتاشیت LT8610ACEMSE-1#TRPBF

مشخصات دیتاشیت

دانلود دیتاشیت LT8610AC Datasheet	LT8610AC Datasheet Datasheet

RoHS: true
Category: Power Supply Chip/DC-DC Converters
Function: Step-down type
Topology: Step-down
Datasheet: Analog Devices LT8610ACEMSE-1#TRPBF
Output Type: Adjustable
Input Voltage: 3V~42V
Output Voltage: 0.8V~42V
Number of Outputs: 1
Switching Frequency: 2.2MHz
Output Current (Max): 3.5A
Operating Temperature: -40°C~+125°C@(TJ)
Synchronous Rectification: Yes
Package: MSOP-16-EP
Manufacturer: Analog Devices
Series: -
Packaging: Tape & Reel (TR)
Part Status: Active
Output Configuration: Positive
Voltage - Input (Min): 3V
Voltage - Input (Max): 42V
Voltage - Output (Min/Fixed): 0.8V
Voltage - Output (Max): 42V
Current - Output: 3.5A
Frequency - Switching: 1.5MHz ~ 2.2MHz
Synchronous Rectifier: Yes
Mounting Type: Surface Mount
Package / Case: 16-TFSOP (0.118", 3.00mm Width) Exposed Pad
Supplier Device Package: 16-MSOP-EP
Base Part Number: LT8610
detail: Buck Switching Regulator IC Positive Adjustable 0.8V 1 Output 3.5A 16-TFSOP (0.118", 3.00mm Width) Exposed Pad
