دیتاشیت LT1507IN8-3.3#PBF
مشخصات دیتاشیت
| نام دیتاشیت | LT1507 |
|---|---|
| حجم فایل | 303.75 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 20 |
دانلود دیتاشیت LT1507 |
LT1507 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/DC-DC Converters
- Function: Step-down type
- Topology: Step-down
- Datasheet: Analog Devices LT1507IN8-3.3#PBF
- Output Type: Fixed
- Input Voltage: 4V~16V
- Output Voltage: 3.3V
- Number of Outputs: 1
- Switching Frequency: 500kHz
- Output Current (Max): 1.5A
- Operating Temperature: -40°C~+85°C@(TA)
- Synchronous Rectification: NO
- Package: PDIP-8
- Manufacturer: Analog Devices
- Series: -
- Packaging: Tube
- Part Status: Active
- Output Configuration: Positive
- Voltage - Input (Min): 4V
- Voltage - Input (Max): 16V
- Voltage - Output (Min/Fixed): 3.3V
- Voltage - Output (Max): -
- Current - Output: 1.5A
- Frequency - Switching: 500kHz
- Synchronous Rectifier: No
- Mounting Type: Through Hole
- Package / Case: 8-DIP (0.300", 7.62mm)
- Supplier Device Package: 8-PDIP
- Base Part Number: LT1507
- detail: Buck Switching Regulator IC Positive Fixed 3.3V 1 Output 1.5A 8-DIP (0.300", 7.62mm)
