دیتاشیت LTC1143LCS-ADJ#TRPBF
مشخصات دیتاشیت
| نام دیتاشیت | LTC1143(L,L-ADJ) |
|---|---|
| حجم فایل | 322.16 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 20 |
دانلود دیتاشیت LTC1143(L,L-ADJ) |
LTC1143(L,L-ADJ) Datasheet |
|---|
مشخصات
- Manufacturer: Linear Technology/Analog Devices
- Series: -
- Packaging: Tape & Reel (TR)
- Part Status: Active
- Output Type: Transistor Driver
- Function: Step-Down, Step-Up/Step-Down
- Output Configuration: Positive
- Topology: Buck, Buck-Boost
- Number of Outputs: 2
- Output Phases: 1
- Voltage - Supply (Vcc/Vdd): 3.5V ~ 16V
- Frequency - Switching: Up to 400kHz
- Duty Cycle (Max): 100%
- Synchronous Rectifier: No
- Clock Sync: No
- Serial Interfaces: -
- Control Features: Current Limit, Enable
- Operating Temperature: 0°C ~ 70°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 16-SOIC (0.154", 3.90mm Width)
- Supplier Device Package: 16-SOIC
- Base Part Number: LTC1143
- detail: Buck, Buck-Boost Regulator Positive Output Step-Down, Step-Up/Step-Down DC-DC Controller IC 16-SOIC
