دیتاشیت LT3752HFE#WPBF

مشخصات دیتاشیت

دانلود دیتاشیت LT3752, LT3752-1	LT3752, LT3752-1 Datasheet

Manufacturer: Linear Technology/Analog Devices
Series: Automotive, AEC-Q100
Packaging: Tube
Part Status: Active
Output Type: Transistor Driver
Function: Step-Up/Step-Down
Output Configuration: Positive, Isolation Capable
Topology: Forward Converter
Number of Outputs: 1
Output Phases: 1
Voltage - Supply (Vcc/Vdd): 6.5V ~ 100V
Frequency - Switching: 100kHz ~ 500kHz
Duty Cycle (Max): 95%
Synchronous Rectifier: Yes
Clock Sync: Yes
Serial Interfaces: -
Control Features: Enable, Frequency Control, Soft Start
Operating Temperature: -40°C ~ 150°C (TJ)
Mounting Type: Surface Mount
Package / Case: 38-PowerTFSOP (0.173", 4.40mm Width), 31 Leads
Supplier Device Package: 38-TSSOP-EP
detail: Forward Converter Regulator Positive, Isolation Capable Output Step-Up/Step-Down DC-DC Controller IC 38-TSSOP-EP
