دیتاشیت LTC3896EFE#TRPBF

مشخصات دیتاشیت

دانلود دیتاشیت LTC3896 Datasheet	LTC3896 Datasheet Datasheet

Manufacturer: Linear Technology/Analog Devices
Series: -
Packaging: Tape & Reel (TR)
Part Status: Active
Output Type: Transistor Driver
Function: Step-Up/Step-Down
Output Configuration: Negative
Topology: Buck-Boost
Number of Outputs: 1
Output Phases: 1
Voltage - Supply (Vcc/Vdd): 4V ~ 140V
Frequency - Switching: 50kHz ~ 900kHz
Duty Cycle (Max): 99%
Synchronous Rectifier: No
Clock Sync: No
Serial Interfaces: -
Control Features: Current Limit, Enable, Frequency Control, Phase Control, Power Good, Soft Start
Operating Temperature: -40°C ~ 125°C (TJ)
Mounting Type: Surface Mount
Package / Case: 38-PowerTFSOP (0.173", 4.40mm Width), 31 Leads
Supplier Device Package: 38-TSSOP-EP
Base Part Number: LTC3896
detail: Buck-Boost Regulator Negative Output Step-Up/Step-Down DC-DC Controller IC 38-TSSOP-EP
