LTC3643EUDD#PBF دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
LTC3643EUDD#PBF
|
|
حجم فایل
|
100.912
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
26
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/DC-DC Converters
-
Function:
boost converterType;Step-down type
-
Topology:
Step-down;Boost
-
Datasheet:
Analog Devices LTC3643EUDD#TRPBF
-
Output Type:
Adjustable
-
Input Voltage:
3V~17V
-
Output Voltage:
0.6V
-
Number of Outputs:
1
-
Switching Frequency:
1MHz
-
Output Current (Max):
2A
-
Operating Temperature:
-40°C~+125°C@(TJ)
-
Synchronous Rectification:
Yes
-
Package:
QFN-24-EP(3x5)
-
Manufacturer:
Analog Devices
-
Series:
-
-
Packaging:
Tape & Reel (TR)
-
Part Status:
Active
-
Output Configuration:
Positive
-
Voltage - Input (Min):
3V
-
Voltage - Input (Max):
17V
-
Voltage - Output (Min/Fixed):
0.6V
-
Voltage - Output (Max):
-
-
Current - Output:
2A
-
Frequency - Switching:
1MHz
-
Synchronous Rectifier:
Yes
-
Mounting Type:
Surface Mount
-
Package / Case:
24-WFQFN Exposed Pad
-
Supplier Device Package:
24-QFN (3x5)
-
Base Part Number:
LTC3643
-
detail:
Buck, Boost Switching Regulator IC Positive Adjustable 0.6V 1 Output 2A 24-WFQFN Exposed Pad
