LTC5589IUF#PBF دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
LTC5589IUF#PBF
|
|
حجم فایل
|
117.742
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
46
|
مشخصات فنی
-
Gain:
-
-
RoHS:
true
-
Category:
Radio Frequency Chip/Antenna/RF Modulators / Demodulator
-
Datasheet:
Analog Devices LTC5589IUF#TRPBF
-
Noise Figure:
-
-
Supply Current:
29.5mA
-
Supply Voltage:
2.7V~3.6V
-
Frequency Range:
700MHz~6GHz
-
Operating Temperature:
-40°C~+105°C
-
Package:
QFN-24-EP(4x4)
-
Manufacturer:
Analog Devices
-
Series:
-
-
Part Status:
Obsolete
-
Function:
Modulator
-
LO Frequency:
-
-
RF Frequency:
700MHz ~ 6GHz
-
P1dB:
4.6dBm
-
Noise Floor:
-160dBm/Hz
-
Output Power:
-6dBm
-
Current - Supply:
29.35mA
-
Voltage - Supply:
2.7V ~ 3.6V
-
Test Frequency:
6GHz
-
Package / Case:
24-WFQFN Exposed Pad
-
detail:
RF Modulator IC 700MHz ~ 6GHz 24-WFQFN Exposed Pad
