دیتاشیت LTC3636EUFD-1#TRPBF
مشخصات دیتاشیت
| نام دیتاشیت | LTpowerCAD II Quick Start Guide |
|---|---|
| حجم فایل | 3567.647 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 36 |
دانلود دیتاشیت LTpowerCAD II Quick Start Guide |
LTpowerCAD II Quick Start Guide Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/DC-DC Converters
- Function: Step-down type
- Topology: Step-down
- Datasheet: Analog Devices LTC3636EUFD-1#TRPBF
- Output Type: Adjustable
- Input Voltage: 3.1V~20V
- Output Voltage: 1.8V~12V
- Number of Outputs: 2
- Output Current (Max): 6A
- Operating Temperature: -40°C~+125°C@(TJ)
- Synchronous Rectification: NO
- Package: QFN-28-EP(4x5)
- Manufacturer: Analog Devices
- Series: -
- Packaging: Tape & Reel (TR)
- Part Status: Active
- Output Configuration: Positive
- Voltage - Input (Min): 3.1V
- Voltage - Input (Max): 20V
- Voltage - Output (Min/Fixed): 1.8V
- Voltage - Output (Max): 12V
- Current - Output: 6A
- Frequency - Switching: Adjustable
- Synchronous Rectifier: No
- Mounting Type: Surface Mount
- Package / Case: 28-WFQFN Exposed Pad
- Supplier Device Package: 28-QFN (4x5)
- Base Part Number: LTC3636
- detail: Buck Switching Regulator IC Positive Adjustable 1.8V 2 Output 6A 28-WFQFN Exposed Pad
