دیتاشیت SI8642ED-B-ISR
مشخصات دیتاشیت
| نام دیتاشیت | SI864x Datasheet |
|---|---|
| حجم فایل | 965.033 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 44 |
دانلود دیتاشیت SI864x Datasheet |
SI864x Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Communication Interface Chip/UART/485/232/Digital Isolators
- Data Rate: 150Mbps
- Datasheet: SILICON LABS SI8642ED-B-ISR
- Applications: General-purpose
- Supply Voltage: 2.5V~5.5V
- Forward Channel: 2
- Reverse channel: 2
- Number of Channels: 4
- Isolation Technology: 电容隔离
- Operating Temperature: -
- Voltage Isolation or Not: 带电压隔离
- Package: SOP-16-300mil
- Manufacturer: SILICON LABS
- Packaging: Cut Tape (CT)
- Type: General Purpose
- Supplier Device Package: 16-SOIC
- Package / Case: 16-SOIC (0.295", 7.50mm Width)
- Propagation Delay tpLH / tpHL (Max): 13ns, 13ns
- Mounting Type: Surface Mount
- Part Status: Active
- Inputs - Side 1/Side 2: 2/2
- Channel Type: Unidirectional
- Pulse Width Distortion (Max): 4.5ns
- Voltage - Isolation: 5000Vrms
- Technology: Capacitive Coupling
- Common Mode Transient Immunity (Min): 35kV/µs
- Rise / Fall Time (Typ): 2.5ns, 2.5ns
- Isolated Power: No
- Series: -
- Voltage - Supply: 2.5V ~ 5.5V
- detail: General Purpose Digital Isolator 5000Vrms 4 Channel 150Mbps 35kV/µs CMTI 16-SOIC (0.295", 7.50mm Width)
