دیتاشیت LT3741IFE-1#TRPBF
مشخصات دیتاشیت
| نام دیتاشیت | LT3741(-1) Datasheet |
|---|---|
| حجم فایل | 639.032 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 24 |
دانلود دیتاشیت LT3741(-1) Datasheet |
LT3741(-1) Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/DC-DC Controllers
- Function: Step-down type
- Topology: Step-down
- Datasheet: Analog Devices LT3741IFE-1#TRPBF
- Input Voltage: 6V~36V
- Duty Cycle (Max): -
- Number of Outputs: 1
- Switching Frequency: 1MHz
- Operating Temperature: -40°C~+125°C@(TJ)
- Synchronous Rectification: Yes
- Package: TSSOP-20-EP
- Manufacturer: Analog Devices
- Series: -
- Packaging: Tape & Reel (TR)
- Part Status: Active
- Output Type: Transistor Driver
- Output Configuration: Positive
- Output Phases: 1
- Voltage - Supply (Vcc/Vdd): 6V ~ 36V
- Frequency - Switching: 200kHz ~ 1MHz
- Synchronous Rectifier: Yes
- Clock Sync: Yes
- Serial Interfaces: -
- Control Features: Enable, Frequency Control, Soft Start
- Mounting Type: Surface Mount
- Package / Case: 20-TSSOP (0.173", 4.40mm Width) Exposed Pad
- Supplier Device Package: 20-TSSOP
- Base Part Number: LT3741
- detail: Buck Regulator Positive Output Step-Down DC-DC Controller IC 20-TSSOP
