دیتاشیت LT1506CR-SYNC#TRPBF
مشخصات دیتاشیت
| نام دیتاشیت | LT1506 |
|---|---|
| حجم فایل | 307.547 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 24 |
دانلود دیتاشیت LT1506 |
LT1506 Datasheet |
|---|
مشخصات
- Manufacturer: Linear Technology/Analog Devices
- Series: -
- Packaging: Tape & Reel (TR)
- Part Status: Active
- Function: Step-Down
- Output Configuration: Positive
- Topology: Buck
- Output Type: Adjustable
- Number of Outputs: 1
- Voltage - Input (Min): 4V
- Voltage - Input (Max): 15V
- Voltage - Output (Min/Fixed): 2.42V
- Voltage - Output (Max): 13.95V
- Current - Output: 4.5A
- Frequency - Switching: 500kHz
- Synchronous Rectifier: No
- Operating Temperature: 0°C ~ 125°C (TJ)
- Mounting Type: Surface Mount
- Package / Case: TO-263-8, D²Pak (7 Leads + Tab), TO-263CA
- Supplier Device Package: D2PAK-7
- Base Part Number: LT1506
- detail: Buck Switching Regulator IC Positive Adjustable 2.42V 1 Output 4.5A TO-263-8, D²Pak (7 Leads + Tab), TO-263CA
