SI8422AD-D-ISR 数据手册
其他文档
SI8410/20/21, SI8422/23 37 pages
技术规格
- RoHS: true
- Category: Communication Interface Chip/UART/485/232/Digital Isolators
- Datasheet: SILICON LABS SI8422AD-D-ISR
- Applications: -
- Isolation Technology: -
- Voltage Isolation or Not: -
- Package: SOP-16-300mil
- Manufacturer: SILICON LABS
- Operating Temperature: -40°C ~ 125°C
- Packaging: Cut Tape (CT)
- Type: General Purpose
- Supplier Device Package: 16-SOIC
- Package / Case: 16-SOIC (0.295", 7.50mm Width)
- Propagation Delay tpLH / tpHL (Max): 35ns, 35ns
- Mounting Type: Surface Mount
- Part Status: Active
- Inputs - Side 1/Side 2: 1/1
- Channel Type: Unidirectional
- Pulse Width Distortion (Max): 25ns
- Voltage - Isolation: 5000Vrms
- Technology: Capacitive Coupling
- Common Mode Transient Immunity (Min): 20kV/µs
- Number of Channels: 2
- Rise / Fall Time (Typ): 2ns, 2ns
- Data Rate: 1Mbps
- Isolated Power: No
- Series: -
- Voltage - Supply: 2.7V ~ 5.5V
- detail: General Purpose Digital Isolator 5000Vrms 2 Channel 1Mbps 20kV/µs CMTI 16-SOIC (0.295", 7.50mm Width)
