دیتاشیت LTC4440AMPMS8E-5#TRPBF

LTC4440A-5

مشخصات دیتاشیت

نام دیتاشیت LTC4440A-5
حجم فایل 366.83 کیلوبایت
نوع فایل pdf
تعداد صفحات 12

دانلود دیتاشیت LTC4440A-5

LTC4440A-5 Datasheet

مشخصات

  • RoHS: true
  • Category: Power Supply Chip/Gate Drive ICs
  • Datasheet: Analog Devices LTC4440AMPMS8E-5#TRPBF
  • Fall Time: 7ns
  • Load Type: MOSFET
  • Rise Time: 10ns
  • Supply Voltage: 4V~15V
  • Number of Drivers: 1
  • Driven Configuration: High Side
  • Operating Temperature: -55°C~+150°C@(Tj)
  • Peak Output Current(sink): 1.1A
  • Peak Output Current(source): 1.1A
  • Package: MSOP-8-EP
  • Manufacturer: Analog Devices
  • Series: -
  • Packaging: Tape & Reel (TR)
  • Part Status: Active
  • Channel Type: Single
  • Gate Type: N-Channel MOSFET
  • Voltage - Supply: 4V ~ 15V
  • Logic Voltage - VIL, VIH: 1.2V, 1.6V
  • Current - Peak Output (Source, Sink): 1.1A, 1.1A
  • Input Type: Non-Inverting
  • High Side Voltage - Max (Bootstrap): 80V
  • Rise / Fall Time (Typ): 10ns, 7ns
  • Mounting Type: Surface Mount
  • Package / Case: 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) Exposed Pad
  • Supplier Device Package: 8-MSOP-EP
  • Base Part Number: LTC4440
  • detail: High-Side Gate Driver IC Non-Inverting 8-MSOP-EP
