دیتاشیت LT3083IT#40PBF
مشخصات دیتاشیت
| نام دیتاشیت | LT3083 Datasheet |
|---|---|
| حجم فایل | 416.5 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 28 |
دانلود دیتاشیت LT3083 Datasheet |
LT3083 Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Analog Devices LT3083IT#40PBF
- Output Type: Adjustable
- Output Current: 3A
- Output Voltage: 0V~23V
- Dropout Voltage: 0.51V@(3A)
- Output Polarity: positive
- Number of Outputs: 1
- Maximum Input Voltage: 23V
- Operating Temperature: -40°C~+125°C
- Quiescent Current (Ground Current): 50.5uA
- Package: TO-220-5
- Manufacturer: Analog Devices
- Series: -
- Packaging: Tube
- Part Status: Active
- Output Configuration: Positive
- Number of Regulators: 1
- Voltage - Input (Max): 23V
- Voltage - Output (Min/Fixed): 0V
- Voltage - Output (Max): 23V
- Voltage Dropout (Max): 0.51V @ 3A
- Current - Output: 3A
- Current - Quiescent (Iq): 50.5µA
- Current - Supply (Max): 1mA
- PSRR: 85dB ~ 20dB (120Hz ~ 1MHz)
- Control Features: -
- Protection Features: Over Current, Over Temperature, Short Circuit
- Mounting Type: Through Hole
- Package / Case: TO-220-5 Formed Leads
- Supplier Device Package: TO-220-5 Flow 40
- Base Part Number: LT3083
- detail: Linear Voltage Regulator IC 1 Output 3A TO-220-5 Flow 40
