- دیتاشیت C8051F121-GQR
دیتاشیت C8051F121-GQR
مشخصات دیتاشیت
| نام دیتاشیت | C8051F121-GQR |
|---|---|
| حجم فایل | 106.61 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 350 |
C8051F121-GQR |
دانلود دیتاشیت |
|---|
سایر مستندات
C8051F12x Datasheet 350 pages
مشخصات فنی
- RoHS: true
- CPU Core: 51Series
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- Watchdog: Yes
- ADC (Bit): 8bit;12bit
- DAC (Bit): 12bit
- Datasheet: SILICON LABS C8051F121-GQR
- CPU Maximum Speed: 100MHz
- GPIO Ports Number: 32
- Low-Voltage Detect: Yes
- Internal Oscillator: Yes
- Program Storage Size: 128KB
- Operating Voltage Range: 3V~3.6V
- Operating Temperature Range: -40°C~+85°C
- Package: TQFP-64(10x10)
- Manufacturer: SILICON LABS
- Oscillator Type: Internal
- Packaging: Cut Tape (CT)
- Core Processor: 8051
- Speed: 100MHz
- Operating Temperature: -40°C ~ 85°C (TA)
- EEPROM Size: -
- Part Status: Not For New Designs
- Peripherals: Brown-out Detect/Reset, POR, PWM, Temp Sensor, WDT
- Package / Case: 64-TQFP
- Connectivity: EBI/EMI, SMBus (2-Wire/I²C), SPI, UART/USART
- Number of I/O: 32
- Core Size: 8-Bit
- Series: C8051F12x
- Program Memory Size: 128KB (128K x 8)
- Program Memory Type: FLASH
- Supplier Device Package: 64-TQFP (10x10)
- Mounting Type: Surface Mount
- RAM Size: 8.25K x 8
- Data Converters: A/D 8x8b, 8x12b; D/A 2x12b
- Voltage - Supply (Vcc/Vdd): 3V ~ 3.6V
- Base Part Number: C8051F12
- detail: 8051 C8051F12x Microcontroller IC 8-Bit 100MHz 128KB (128K x 8) FLASH 64-TQFP (10x10)
