- دیتاشیت C8051F380-GQR
C8051F380-GQR دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | C8051F380-GQR |
|---|---|
| حجم فایل | 86.674 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 2 |
دانلود دیتاشیت C8051F380-GQR |
دانلود دیتاشیت |
|---|
سایر مستندات
C8051F380-87/C 321 pages
C8051F38x Errata 1 pages
مشخصات فنی
- RoHS: true
- CPU Core: 51Series
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- Watchdog: Yes
- ADC (Bit): 10bit
- Datasheet: SILICON LABS C8051F380-GQR
- CPU Maximum Speed: -
- GPIO Ports Number: 40
- Low-Voltage Detect: Yes
- Internal Oscillator: Yes
- Peripheral/Function: Temperature transducer
- Program Storage Size: 64KB
- Universal Serial Bus: Yes
- Operating Voltage Range: 2.7V~5.25V
- Operating Temperature Range: -40°C~+85°C
- Secure Digital Input and Output: -
- Package: TQFP-48(7x7)
- Manufacturer: SILICON LABS
- Oscillator Type: Internal
- Packaging: Cut Tape (CT)
- Core Processor: 8051
- Speed: 48 MIPS
- Operating Temperature: -40°C ~ 85°C (TA)
- EEPROM Size: -
- Part Status: Active
- Peripherals: Brown-out Detect/Reset, POR, PWM, Temp Sensor, WDT
- Package / Case: 48-TQFP
- Connectivity: EBI/EMI, I²C, SPI, UART/USART, USB
- Number of I/O: 40
- Core Size: 8-Bit
- Series: C8051F38x
- Program Memory Size: 64KB (64K x 8)
- Program Memory Type: FLASH
- Supplier Device Package: 48-TQFP (7x7)
- Mounting Type: Surface Mount
- RAM Size: 4.25K x 8
- Data Converters: A/D 32x10b
- Voltage - Supply (Vcc/Vdd): 2.7V ~ 5.25V
- Base Part Number: C8051F38
- detail: 8051 C8051F38x Microcontroller IC 8-Bit 48 MIPS 64KB (64K x 8) FLASH 48-TQFP (7x7)
