دیتاشیت LTC3115IDHD-1#WPBF

مشخصات دیتاشیت

دانلود دیتاشیت LTC3115-1 Datasheet	LTC3115-1 Datasheet Datasheet

Manufacturer: Linear Technology/Analog Devices
Series: Automotive, AEC-Q100
Packaging: Tube
Part Status: Active
Function: Step-Up/Step-Down
Output Configuration: Positive
Topology: Buck-Boost
Output Type: Adjustable
Number of Outputs: 1
Voltage - Input (Min): 2.7V
Voltage - Input (Max): 40V
Voltage - Output (Min/Fixed): 2.7V
Voltage - Output (Max): 40V
Current - Output: 800mA, 2A
Frequency - Switching: 100kHz ~ 2MHz
Synchronous Rectifier: Yes
Operating Temperature: -40°C ~ 125°C (TJ)
Mounting Type: Surface Mount
Package / Case: 16-WFDFN Exposed Pad
Supplier Device Package: 16-DFN (5x4)
detail: Buck-Boost Switching Regulator IC Positive Adjustable 2.7V 1 Output 800mA, 2A 16-WFDFN Exposed Pad
