LTC2654 Datasheet Datasheet

LTC2654 Datasheet

Datasheet specifications

Datasheet's name LTC2654 Datasheet
File size 356.226 KB
File type pdf
Number of pages 24

Download Datasheet LTC2654 Datasheet

Download Datasheet

Other documentations

LTC2654BCGN-H16#PBF 24 pages

Technical specifications

  • RoHS: true
  • Category: ADC/DAC/Data Conversion/Digital To Analog Converters (DACs)
  • Datasheet: Analog Devices LTC2654IGN-H12#TRPBF
  • Interface: SPI
  • Resolution: 12Bit
  • Output Type: Voltage-缓冲
  • Settling Time: 4.2us
  • Supply Voltage: 5V
  • Integral nonlinearity: ±0.5LSB;±0.1LSB
  • Operating Temperature: -40°C~+85°C
  • Package: SSOP-16-150mil
  • Manufacturer: Analog Devices
  • Series: -
  • Packaging: Tape & Reel (TR)
  • Part Status: Active
  • Number of Bits: 12
  • Number of D/A Converters: 4
  • Differential Output: No
  • Data Interface: SPI
  • Reference Type: External, Internal
  • Voltage - Supply, Analog: 5V
  • Voltage - Supply, Digital: 5V
  • INL/DNL (LSB): ±0.5, ±0.1
  • Architecture: -
  • Package / Case: 16-SSOP (0.154", 3.90mm Width)
  • Supplier Device Package: 16-SSOP
  • Mounting Type: Surface Mount
  • Base Part Number: LTC2654
  • detail: 12 Bit Digital to Analog Converter 4 16-SSOP
