دیتاشیت General Purpose SAR ADCs Selection Guide

General Purpose SAR ADCs Selection Guide

مشخصات دیتاشیت

نام دیتاشیت General Purpose SAR ADCs Selection Guide
حجم فایل 1269.91 کیلوبایت
نوع فایل pdf
تعداد صفحات 2

General Purpose SAR ADCs Selection Guide

دانلود دیتاشیت

سایر مستندات

LTC2311-12 Datasheet 24 pages

LTC2311CMSE-12#PBF 24 pages

مشخصات فنی

  • RoHS: true
  • Category: ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
  • Datasheet: Analog Devices LTC2311IMSE-12#TRPBF
  • Interface: serial;SPI
  • resolution: 12Bit
  • Supply Voltage: 3.13V~3.47V;5V
  • differential input: Yes
  • number of channels: 1
  • sampling frequency: 5MHz
  • Operating Temperature: -40°C~+85°C
  • Package: MSOP-16-EP
  • Manufacturer: Analog Devices
  • Series: -
  • Packaging: Tape & Reel (TR)
  • Part Status: Active
  • Number of Bits: 12
  • Sampling Rate (Per Second): 5M
  • Number of Inputs: 1
  • Input Type: Differential, Pseudo-Differential
  • Data Interface: LVDS - Serial, SPI
  • Configuration: S/H-ADC
  • Ratio - S/H:ADC: 1:1
  • Number of A/D Converters: 1
  • Architecture: SAR
  • Reference Type: External, Internal
  • Voltage - Supply, Analog: 3.13V ~ 3.47V, 5V
  • Voltage - Supply, Digital: 3.13V ~ 3.47V, 5V
  • Features: -
  • Package / Case: 16-TFSOP (0.118", 3.00mm Width) Exposed Pad
  • Supplier Device Package: 16-MSOP
  • Mounting Type: Surface Mount
  • Base Part Number: LTC2311
  • detail: 12 Bit Analog to Digital Converter 1 Input 1 SAR 16-MSOP
