SI8220CB-D-IS Datasheet

SI8220/21

Datasheet specifications

Datasheet's name SI8220/21
File size 1546.047 KB
File type pdf
Number of pages 31

Download Datasheet SI8220/21

Download Datasheet

Other documentations

No other documentation was found!

Technical specifications

  • Manufacturer: Silicon Labs
  • Package / Case: 8-SOIC (0.154", 3.90mm Width)
  • Rise / Fall Time (Typ): 20ns, 20ns (Max)
  • Number of Channels: 1
  • Approval Agency: CQC, CSA, UR, VDE
  • Pulse Width Distortion (Max): -
  • Technology: Capacitive Coupling
  • Voltage - Forward (Vf) (Typ): 2.5V (Max)
  • Current - Peak Output: 2.5A
  • Series: Automotive, AEC-Q100
  • Voltage - Output Supply: 12.2V ~ 24V
  • Operating Temperature: -40°C ~ 125°C
  • Common Mode Transient Immunity (Min): 30kV/µs (Typ)
  • Current - DC Forward (If) (Max): 30mA
  • Current - Output High, Low: 1.5A, 2.5A
  • Propagation Delay tpLH / tpHL (Max): 60ns, 40ns
  • Part Status: Active
  • Voltage - Isolation: 2500Vrms
  • Mounting Type: Surface Mount
  • Supplier Device Package: 8-SOIC
  • Packaging: Tube
  • detail: 2.5A Gate Driver Capacitive Coupling 2500Vrms 1 Channel 8-SOIC
