SI8274DB4D-IS1 Datasheet

SI827x Datasheet

Datasheet specifications

Datasheet's name SI827x Datasheet
File size 841.093 KB
File type pdf
Number of pages 49

Download Datasheet SI827x Datasheet

Download Datasheet

Other documentations

No other documentation was found!

Technical specifications

  • Manufacturer: Silicon Labs
  • Package / Case: 16-SOIC (0.154", 3.90mm Width)
  • Rise / Fall Time (Typ): 10.5ns, 13.3ns
  • Number of Channels: 2
  • Approval Agency: CQC, CSA, UL, VDE
  • Pulse Width Distortion (Max): 47ns
  • Technology: Capacitive Coupling
  • Voltage - Forward (Vf) (Typ): -
  • Current - Peak Output: 4A
  • Series: Automotive, AEC-Q100
  • Voltage - Output Supply: 4.2V ~ 30V
  • Operating Temperature: -40°C ~ 125°C
  • Common Mode Transient Immunity (Min): 200kV/µs
  • Propagation Delay tpLH / tpHL (Max): 105ns, 105ns
  • Part Status: Active
  • Voltage - Isolation: 2500Vrms
  • Mounting Type: Surface Mount
  • Supplier Device Package: 16-SOIC
  • Current - Output High, Low: 1.8A, 4A
  • detail: 4A Gate Driver Capacitive Coupling 2500Vrms 2 Channel 16-SOIC
