ATZB-A24-UFLBR دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
ATZB-A24-UFLB/U0B
|
|
حجم فایل
|
3875.127
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
22
|
مشخصات فنی
-
Manufacturer:
Microchip Technology
-
Series:
ZigBit™
-
Packaging:
Cut Tape (CT)
-
Part Status:
Obsolete
-
RF Family/Standard:
802.15.4
-
Protocol:
Zigbee®
-
Modulation:
-
-
Frequency:
2.4GHz
-
Data Rate:
250kbps
-
Power - Output:
20dBm
-
Sensitivity:
-101dBm
-
Serial Interfaces:
I²C, JTAG, SPI, UART, USART
-
Antenna Type:
Antenna Not Included, U.FL
-
Utilized IC / Part:
AT86RF230
-
Memory Size:
128kB Flash, 4kB EEPROM, 8kB RAM
-
Voltage - Supply:
3V ~ 3.6V
-
Current - Receiving:
39.5mA
-
Current - Transmitting:
183.5mA
-
Mounting Type:
Surface Mount
-
Operating Temperature:
-20°C ~ 70°C
-
Package / Case:
Module
-
detail:
802.15.4 Zigbee® Transceiver Module 2.4GHz Antenna Not Included, U.FL Surface Mount
