MCP87130 دیتاشیت

MCP87130

مشخصات دیتاشیت

نام دیتاشیت MCP87130
حجم فایل 1043.428 کیلوبایت
نوع فایل pdf
تعداد صفحات 18

مشاهده دیتاشیت MCP87130

دانلود دیتاشیت

سایر مستندات

MCP87130T-U/LC 18 pages

مشخصات فنی

  • RoHS: true
  • Type: N Channel
  • Category: Triode/MOS Tube/Transistor/MOSFETs
  • Datasheet: Microchip Tech MCP87130T-U/LC
  • Power Dissipation (Pd): 1.7W
  • Drain Source Voltage (Vdss): 25V
  • Continuous Drain Current (Id): 43A
  • Gate Threshold Voltage (Vgs(th)@Id): 1.7V@250uA
  • Drain Source On Resistance (RDS(on)@Vgs,Id): 13.5mΩ@10V,10A
  • Package: DFN-8(3x3)
  • Manufacturer: Microchip Tech
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Obsolete
  • FET Type: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 25V
  • Current - Continuous Drain (Id) @ 25°C: 43A (Tc)
  • Drive Voltage (Max Rds On, Min Rds On): 3.3V, 10V
  • Rds On (Max) @ Id, Vgs: 13.5mOhm @ 10A, 10V
  • Vgs(th) (Max) @ Id: 1.7V @ 250µA
  • Gate Charge (Qg) (Max) @ Vgs: 8nC @ 4.5V
  • Vgs (Max): +10V, -8V
  • Input Capacitance (Ciss) (Max) @ Vds: 400pF @ 12.5V
  • FET Feature: -
  • Power Dissipation (Max): 1.7W (Ta)
  • Operating Temperature: -55°C ~ 150°C (TJ)
  • Mounting Type: Surface Mount
  • Supplier Device Package: 8-PDFN (3x3)
  • Package / Case: 8-PowerTDFN
  • Base Part Number: MCP87130
  • detail: N-Channel 25V 43A (Tc) 1.7W (Ta) Surface Mount 8-PDFN (3x3)
