- دیتاشیت EFM8BB1 Datasheet
EFM8BB1 Datasheet دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | EFM8BB1 Datasheet |
|---|---|
| حجم فایل | 1107.009 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 57 |
دانلود دیتاشیت EFM8BB1 Datasheet |
دانلود دیتاشیت |
|---|
سایر مستندات
EFM8BB1 Reference Manual 238 pages
EFM8BB10F8G-A-QFN20R 57 pages
مشخصات فنی
- CAN: -
- I2C: -
- I2S: -
- SPI: -
- RoHS: true
- EEPROM: -
- CPU Core: 51Series
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- RAM Size: 512Byte
- Watchdog: Yes
- ADC (Bit): 12bit
- DAC (Bit): -
- Datasheet: SILICON LABS EFM8BB10F8G-A-SOIC16R
- PWM (Bit): -
- 8Bit Timer: -
- UART/USART: -
- 16Bit Timer: -
- 32Bit Timer: -
- Real-Time Clock: -
- CPU Maximum Speed: 25MHz
- GPIO Ports Number: 13
- Low-Voltage Detect: Yes
- CCP Capture/Compare: -
- Internal Comparator: -
- Internal Oscillator: Yes
- Peripheral/Function: WDT
- Program Memory Type: FLASH
- Direct Memory Access: -
- Program Storage Size: 8KB
- Universal Serial Bus: -
- communication protocol: -
- Operating Voltage Range: 2.2V~3.6V
- Infrared Data Association: -
- Operating Temperature Range: -40°C~+85°C
- Secure Digital Input and Output: -
- Package: SOP-16
- Manufacturer: SILICON LABS
- Number of I/O: 13
- EEPROM Size: -
- Speed: 25MHz
- Supplier Device Package: 16-SOIC
- Package / Case: 16-SOIC (0.154", 3.90mm Width)
- Core Processor: CIP-51 8051
- Series: Automotive, AEC-Q100, Busy Bee
- Voltage - Supply (Vcc/Vdd): 2.2V ~ 3.6V
- Operating Temperature: -40°C ~ 85°C (TA)
- Oscillator Type: Internal
- Program Memory Size: 8KB (8K x 8)
- Mounting Type: Surface Mount
- Part Status: Active
- Data Converters: A/D 12x12b
- Packaging: Cut Tape (CT)
- Connectivity: I²C, SMBus, SPI, UART/USART
- Peripherals: Brown-out Detect/Reset, POR, PWM, WDT
- Core Size: 8-Bit
- detail: CIP-51 8051 Automotive, AEC-Q100, Busy Bee Microcontroller IC 8-Bit 25MHz 8KB (8K x 8) FLASH 16-SOIC
