دیتاشیت SI8630AB-B-IS1
مشخصات دیتاشیت
| نام دیتاشیت |
Si86xx
|
| حجم فایل |
643.747
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
47
|
مشخصات
-
Manufacturer:
Silicon Labs
-
Package / Case:
16-SOIC (0.295", 7.50mm Width)
-
Rise / Fall Time (Typ):
2.5ns, 2.5ns
-
Number of Channels:
3
-
Operating Temperature:
-40°C ~ 125°C
-
Pulse Width Distortion (Max):
25ns
-
Data Rate:
1Mbps
-
Technology:
Capacitive Coupling
-
Supplier Device Package:
16-SOIC
-
Series:
-
-
Voltage - Supply:
2.5V ~ 5.5V
-
Isolated Power:
No
-
Inputs - Side 1/Side 2:
3/0
-
Common Mode Transient Immunity (Min):
35kV/µs
-
Channel Type:
Unidirectional
-
Type:
General Purpose
-
Propagation Delay tpLH / tpHL (Max):
35ns, 35ns
-
Part Status:
Active
-
Voltage - Isolation:
2500Vrms
-
Mounting Type:
Surface Mount
-
Packaging:
Tube
-
detail:
General Purpose Digital Isolator 2500Vrms 3 Channel 1Mbps 35kV/µs CMTI 16-SOIC (0.295", 7.50mm Width)
