دیتاشیت C8051F966-B-GM
مشخصات دیتاشیت
| نام دیتاشیت |
C8051F96x
|
| حجم فایل |
14663.33
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
512
|
مشخصات
-
RoHS:
true
-
CPU Core:
51Series
-
Category:
Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
-
Watchdog:
Yes
-
ADC (Bit):
10bit;12bit
-
Datasheet:
SILICON LABS C8051F966-B-GM
-
LCD Module:
Yes
-
CPU Maximum Speed:
25MHz
-
GPIO Ports Number:
57
-
Low-Voltage Detect:
Yes
-
Internal Oscillator:
Yes
-
Direct Memory Access:
Yes
-
Program Storage Size:
32KB
-
Operating Voltage Range:
1.8V~3.8V
-
Operating Temperature Range:
-40°C~+85°C
-
Package:
DQFN-76(6x6)
-
Manufacturer:
SILICON LABS
-
Number of I/O:
57
-
Program Memory Type:
FLASH
-
EEPROM Size:
-
-
RAM Size:
8.25K x 8
-
Speed:
25MHz
-
Supplier Device Package:
76-DQFN (6x6)
-
Package / Case:
76-VFQFN Dual Rows, Exposed Pad
-
Core Processor:
8051
-
Series:
C8051F9xx
-
Voltage - Supply (Vcc/Vdd):
1.8V ~ 3.8V
-
Operating Temperature:
-40°C ~ 85°C (TA)
-
Oscillator Type:
Internal
-
Program Memory Size:
32KB (32K x 8)
-
Mounting Type:
Surface Mount
-
Part Status:
Active
-
Data Converters:
A/D 16x10b/12b
-
Packaging:
Tray
-
Connectivity:
I²C, SPI, UART/USART
-
Peripherals:
DMA, LCD, POR, PWM, WDT
-
Core Size:
8-Bit
-
detail:
8051 C8051F9xx Microcontroller IC 8-Bit 25MHz 32KB (32K x 8) FLASH 76-DQFN (6x6)
