دیتاشیت BGX13S22GA-V31R

BGX13S

مشخصات دیتاشیت

نام دیتاشیت BGX13S
حجم فایل 2422.152 کیلوبایت
نوع فایل pdf
تعداد صفحات 42

دانلود دیتاشیت BGX13S

BGX13S Datasheet

مشخصات

  • Manufacturer: Silicon Labs
  • Modulation: GFSK
  • Voltage - Supply: 2.4V ~ 3.8V
  • Operating Temperature: -40°C ~ 85°C (TA)
  • Current - Transmitting: 3.5mA ~ 7mA
  • Data Rate: 2Mbps
  • Sensitivity: -94.1dBm
  • Protocol: Bluetooth v5.0
  • Power - Output: 8dBm
  • Package / Case: 51-SMD Module
  • Current - Receiving: 3.5mA ~ 7mA
  • Series: Blue Gecko
  • Antenna Type: Integrated, Chip
  • RF Family/Standard: Bluetooth
  • Mounting Type: Surface Mount
  • Utilized IC / Part: BGX13S
  • Part Status: Active
  • Frequency: 2.4GHz ~ 2.4835GHz
  • Memory Size: -
  • Serial Interfaces: UART, USART
  • Packaging: Cut Tape (CT)
  • detail: Bluetooth Bluetooth v5.0 Transceiver Module 2.4GHz ~ 2.4835GHz Integrated, Chip Surface Mount
