دیتاشیت LTC2292CUP#TRPBF
مشخصات دیتاشیت
| نام دیتاشیت |
LTC2291-93
|
| حجم فایل |
1124.398
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
28
|
مشخصات
-
RoHS:
true
-
Category:
ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
-
Datasheet:
Analog Devices LTC2292CUP#TRPBF
-
Interface:
Parallel
-
resolution:
12Bit
-
Supply Voltage:
2.7V~3.4V
-
differential input:
Yes
-
number of channels:
2
-
sampling frequency:
40MHz
-
Operating Temperature:
0°C~+70°C
-
Package:
QFN-64-EP(9x9)
-
Manufacturer:
Analog Devices
-
Series:
-
-
Packaging:
Tube
-
Part Status:
Obsolete
-
Number of Bits:
12
-
Sampling Rate (Per Second):
40M
-
Number of Inputs:
2
-
Input Type:
Differential, Single Ended
-
Data Interface:
Parallel
-
Configuration:
S/H-ADC
-
Ratio - S/H:ADC:
1:1
-
Number of A/D Converters:
2
-
Architecture:
Pipelined
-
Reference Type:
External, Internal
-
Voltage - Supply, Analog:
2.7V ~ 3.4V
-
Voltage - Supply, Digital:
2.7V ~ 3.4V
-
Features:
Simultaneous Sampling
-
Package / Case:
64-WFQFN Exposed Pad
-
Supplier Device Package:
64-QFN (9x9)
-
Mounting Type:
Surface Mount
-
detail:
12 Bit Analog to Digital Converter 2 Input 2 Pipelined 64-QFN (9x9)
